LS Tractor XR3100 Series

This is a 24.4 horsepower, geared transmission tractor. Comes with loader and 66″ bucket. And since tractor is under 25HP, it does not require a DPF or DEF!

LS Tractor XR3100 Series

This is a 24.4 horsepower, geared transmission tractor. Comes with loader and 66″ bucket. And since tractor is under 25HP, it does not require a DPF or DEF!

Categories: , Tag:

Product Enquiry

Your Zip Code(Required)

Contact the Seller

The XR3100 series tractor is a premium model tractor that comes with a 35 horsepower LS 3-cylinder turbocharged diesel engine that meets the current tier 4 emission standards. This tractor comes with either a manual 12 forward x 12 reverse fully synchronized shuttle shift or a three-range hydrostatic transmission. This difference between this tractor and the XG3100 Series is that this tractor comes with dual remotes pre-installed, a beefier frame so that the loader can handle more weight (2,178 lbs vs. 1,700 lbs), a larger and more conveniently located fuel tank, and a lot of little things that just make this a more comfortable and capable tractor. Another difference is that this series can come with a cab that includes AC and heat! This tractor is great for homeowners who are limited on size but want the most from their compact tractor. This tractor comes with a loader with a 66” bucket. Other attachments, such as backhoes, are also available.

Download Brochure

XR3135 Features

  • Engine HP - 35
  • PTO HP – 30.1
  • Transmission - Fully Synchronized 12 forward x 12 reverse synchro shuttle
  • 3-Point Lift Capacity - 1,808 lbs
  • Loader Lift Capacity - 2,178 lbs

XR3135H Features

  • Engine HP - 35
  • PTO HP – 28
  • Transmission - 3-Range Hydrostatic Drive (HST)
  • 3-Point Lift Capacity - 1,808 lbs
  • Loader Lift Capacity - 2,178 lbs

XR3135C Features

  • Engine HP - 35
  • PTO HP – 30.1
  • Transmission - Fully Synchronized 12 forward x 12 reverse synchro shuttle
  • 3-Point Lift Capacity - 1,808 lbs
  • Loader Lift Capacity - 2,178 lbs

XR3135HC Features

  • Engine HP - 35
  • PTO HP – 28
  • Transmission - 3-Range Hydrostatic Drive (HST)
  • 3-Point Lift Capacity - 1,808 lbs
  • Loader Lift Capacity - 2,178 lbs

Additional information

Horsepower

30-35

Fuel Tank Capacity

10 Gallon

Loader Capacity

2,000-2,500 lbs

PTO Horsepower

25-30
